Details
Features
- Latest addition to the HSD lineup, ideal for tackling hills
- Powerful Bosch® Performance Line motor for up to 65 Nm of torque
- 500 Wh battery for a range of up to 118 km (74 mi)
- Custom Suntour suspension fork
- 9-speed Shimano® Alivio Shadow derailleur
- Shimano hydraulic disc brakes
- Abus® keyed-alike frame lock
- Fits riders from 150 to 195 cm (4’11” – 6’5”)
- Fits one Thule® Yepp Maxi, Yepp Nexxt Maxi, or Bobike® GO Maxi child seat—no adapters needed
Specs
Frame | Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 170 kg |
---|---|
Fork | Suntour custom for Tern, Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 170 kg |
Headset | Tern Flux by FSA, cartridge bearings, Physis integrated |
Spokes | Stainless steel |
Tires | Schwalbe Big Apple, 55-406, puncture protection, Reflex |
Crankset | Tern HSD custom |
Chain | 9 spd, DHT for eBike, GST corrosion resistant coating |
Rear Cogs | Shimano 11-32T, 9 spd |
Shifters | Shimano Alivio, 1 x 9 spd, trigger |
Handlebars | Tern Sweep, 6061-AL, Tern Andros adapted |
Tape/Grips | Ergon |
Stem | Tern Andros, adjustable, forged construction, patented technology |
Brake Levers | Shimano, hydraulic disc |
Pedals | Urban with non-slip surface |
Saddle | Tern Upright by Velo |
Seat Post | Tern Telescope, 34.9/30.9 mm, 2014-AL |
Seat Binder | Tern Collar |
Handlepost | Tern Physis 3D, 3D forged, 5 patented technologies, 12°, 290 mm |
Front Brake | Shimano, hydraulic disc, 180 mm rotor |
Rear Brake | Shimano, hydraulic disc, 160 mm rotor |
Front Wheel | Tern Atlas H, cargo wheel |
Rear Wheel | Tern Atlas H, cargo wheel |
Front Hub | Novatec, Thru-axle, sealed bearings |
Rear Hub | Shimano disc |
Rims | Tern Atlas H, wide 35 mm |
Motor | Bosch Performance, 300% Assist, 65 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US) |
Battery | Bosch PowerPack 500 |
Display | Bosch Purion |
Range | 500 Wh: 51-118 km (32-74 mi) with ABUS, keyed-alike with Bosch battery |
Charger | 220V, 4A (EU); 100-240V, 4A (US) |
Bell | Aluminum |
Chainguard | SKS Chainblade |
Kickstand | Ursus, rear mount |
Front Light | Tern Valo Direct, 190 lumens |
Rear Light | Herrmans H-Trace, for eBike |
Fenders | SKS, stainless hardware |
Rack | Atlas H rack, Atlas Rack Mount, 6 point mounting, 60 kg capacity |
Weight | 25.7 kg (56.7 lb) |
Folded Size | 163 × 40.5 × 86 cm (64.2 × 15.9 × 33.9 in) |
Max Gross Weight | 170 kg (374.8 lb) MAX RIDER WEIGHT: 120 kg (264.6 lb) |
Max Rider Weight | 120 kg (264.6 lb) |
* Subject to change without notice.
