Details
Level Up.
A mountain bike built to raise your game and ignite a passion for the trail. Designed for the mountains and ready for anything.
Where it thrives
Low-impact trails, gravel roads, leisurely ride
What it's built for
Handling, durability
Specs
Frame | Trail, SmartForm C3 Alloy, 142x12mm, SAVE, 1-1/8" headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, KickFlip hidden 18mm 2-bolt kickstand mount, BSA-73, 27.5" wheels (XS, S) / 29" wheels (M, L, XL) |
---|---|
Rims | WTB SX19, 32h |
Spokes | Stainless Steel, 14g |
Pedals | Not Included |
Bottom Bracket | ProWheel, square taper |
Rear Cogs | Shimano CUES, 11-46, 9-speed |
Shifters | Shimano CUES U4000, 9-speed |
Grips | Cannondale |
Headset | Semi-Integrated, 1-1/8" |
Saddle | Cannondale Trail |
Fork | SR Suntour XCM, 100mm, coil, 42mm offset (27.5") 46mm offset (29") |
Hubs | (F) Formula DC-51, 15x100mm / (R) Formula DC-1422, 12x142mm |
Tires | WTB Ranger, 27.5x2.25" (XS, S) / 29x2.25" (M, L, XL) |
Crank | Prowheel, Charm 30T |
Chain | KMC X9, 9-speed |
Rear Derailleur | Shimano CUES U4000 |
Handlebar | Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm |
Stem | Cannondale 4, 6061 Alloy, 31.8, 6° |
Brakes | Tektro M275 hydraulic disc, 160/160mm rotors |
Seatpost | Cannondale 4, 6061 Alloy, 31.6 |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Ion Blue / Medium / 29-inch | 196870182561 | C26065U30MD | 210000154040 |
Ion Blue / Large / 29-inch | 196870182578 | C26065U30LG | 210000154041 |
Ion Blue / X-Large / 29-inch | 196870182585 | C26065U30XL | 210000154042 |
Black / X-Small / 27.5-inch | 196870182448 | C26065U10XS | 210000154028 |
Metallic Red / X-Large / 29-inch | 196870182530 | C26065U20XL | 210000154037 |
