BMC Kaius 01 Three

BMC Kaius 01 Three
Please select options


Kaius is a premium carbon gravel bike built to be your elite race companion for all terrains. The unprecedented carbon layup and gravel-specific geometry ensure the perfect balance of stiffness, lightweight, and compliance for optimal traction on loose surfaces, front-end stability, and unmatched climbing prowess. Harnessing the precision and performance of our renowned leading road technologies, Kaius is a race machine tuned to the gravel wavelength with the engineered Kaius fork, our signature ICS2 stem and conventional bar, TCC Race compliance, compatibility with 1x and 2x drivetrains and up to 44 mm of tire clearance.


Frame Kaius 01 Premium Carbon with Aerocore Design | ICS Technology, Stealth Cable Routing | Integrated Aerocore Bottle Cages | Stealth Dropout Design | TCC Race Compliance Level | PF86 Bottom Bracket | Flat Mount Disc | 12x142mm Thru-Axle
Fork Kaius 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12x100mm Thru-Axle
Rims CRD-400 Carbon, Tubeless Ready, 40mm
Hubs CRD-400
Tires Pirelli Cinturato Gravel H, 40mm
Crankset SRAM RIVAL Dub WIDE 43-30T
Chain SRAM RIVAL 12 Speed
Rear Cog(s) SRAM RIVAL AXS XG-1250 10-36T
Handlebars BMC RAB 02, Ergo Top Shape, Compact Bend
Stem BMC ICS2 - Integrated Cockpit Design
Saddle Fizik Vento Argo R5 - 140mm
Seat Post Kaius 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Accessories & Extras Aerocore Bottle Cages
Rear Derailleur SRAM RIVAL eTap AXS WIDE
Brakes SRAM Rival eTap AXS HRD, Paceline Rotors (160/160)
Tire Clearance 44mm (Measured Width)

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Purple / 47cm 7630906508916 30005314 210000144253
Purple / 51cm 7630906508909 30005315 210000144254
Purple / 54cm 7630906508893 30005316 210000144255
Purple / 56cm 7630906508886 30005317 210000144256
Purple / 58cm 7630906508879 30005318 210000144257
